LA36400 | Square D 400 amp Circuit Breaker

LA36400 Circuit Breaker

Product Details
Manufacturer:Square D
Amperage:400
Poles:3
Voltage:240 VAC 480 VAC 600 VAC

Purchase Options

Need a Square D LA36400 Circuit Breaker? Then search no further. Buy now from the Internet's #1 electrical supply house. LiveWire Supply offers great prices, fast delivery and unmatched support for all your circuit breaker needs.

Buy LA36400 Circuit Breaker

Guaranteed New

Certified Green

Click Buy Now for additional details and pricing.

Additional Product Details
kAIC Ratings:42 KAIC at 240 Voltgs
30 KAIC at 480 Volts
22 KAIC at 600 Volts
Lug Kits:AL400LA = 1-#1 AWG-600 kcmil

Mounting Hardware:I-Line Panel Mounted -- Does not require hardware

Dimensions:6 w x 11 h x 4 d
Common Accessories:add 1021 to end of part for Shunt Trip = LA364001021
add 1121 to the end of part for UVR = LA364001121
Catalogue Data Sheet:   Click to download or view PDF

Product Description

Thermomagnetic circuit breakers, like the LA36400 is commonly found in many Square D panels or distribution boards. The electromagnet characteristics of the [part allow it to trip instantaneously under large surges in current (e.g., short circuits). A bimetallic strip within the LA36400 will respond to less extreme but longer-term over-current conditions. The LA36400 is a common breaker for commercial or light industrial application; such as, lighting, small motors, printing presses or other electrically powered devices or outlets. This style of circuit breaker is sometimes used as a main breaker or a sub-feed to a sub panel.

Check with LiveWireSupply for price, availability or obsolete status of the LA36400. They are a reliable source to buy the LA36400 and they always have competitive pricing.

Square D Molded Case Circuit Breakers, like the LA36400 are designed to provide circuit protection for low voltage distribution protection for low voltage distribution systems. The LA36400 is described by NEMA as, "a device for closing and interrupting a circuit between separable contacts under both normal and abnormal conditions," and furthermore as, ". . . a breaker like the LA36400 assembled as an integral unit in a supporting and enclosing housing of insulating material." The NEC describes them as, "A device designed to open and close a circuit by non-automatic means, and to open the circuit automatically on a predetermined overload of current, without injury to itself when properly applied within its rating."

Hopefully, you consider LA36400.com a helpful source for technical specification and a good source for the catalogue data sheet. Check back often for deals and sales from time to time. We consider this an authoritative resource for great pricing and reliable information.

This photo is for reference purposes.
